Name: AllinOne Digital Label Printing Foiling and Die Cutting Machine
Brand: EcooGraphix
Price: 1 USD

Brand Name : EcooGraphix

Model Number : ECOO ZBS 320

Certification : ISO9000, CE

Place of Origin : China

MOQ : 1 SET

Price : Negotiable

Payment Terms : T/T

Supply Ability : 500 Sets/Year

Delivery Time : 30 DAYS

Packaging Details : Standard Export Packing

Max. roll diameter : 350mm

Machine Type : Label Printing Machine

Max. Rewinding Diameter : 600mm

Model : Ecoo Label IQ-330

Max. media width : 330mm

Max. Unwinding Diameter : 600mm

Contact Now

Product Description

Integrated Versatility: One machine, infinite possibilities. The Ecoo Label IQ-330 combines printing, laminating, cutting, and slitting into a single device, simplifying your production line and enhancing overall efficiency.
Excellent Printing Performance: Whether using white, varnish, or colored UV inks, the Ecoo Label IQ-330 delivers outstanding print quality on a wide range of media, helping your labels stand out on the shelf.
High precision cutting: Featuring ball screws and independent servo motors, the machine achieves a cutting accuracy of ±0.1mm, ensuring flawless labels every time.
Wide Range of Applications: From food packaging and cosmetic labels to electronic product identification and industrial data encoding, the Ecoo Label IQ-330 handles it all with ease.

Digital Label Printing Machine
Model	Ecoo Label IQ-330
Max. roll diameter	350mm
Max. media width	330mm
Print head	EP i3200-U1x4
Ink Type	UV ink
Ink color	CMYK+W+V
Ink bottle capacity	1L
Print speed	4pass:56m/h 6pass:40m/h 8pass:28m/h
File format	JPG/ PNG/ PDF
Cutting length	10-350mm
Cutting width	10-320mm
Repeat die-cutting accuracy	0.1mm
Number of die-cutting heads	2
Number of slitting knives	Standard 3 (optional according to requirements)
Power consumption	4kW
Power supply	AC220-240V, 50-60hz
Weight	2000KGS
Printer size	*2500mm1800mm1700mm*
Laminating specification	Wide 330mm
Gold foil standard	Hot foil stamping
Printing resolution	*7201200 7201800 7202400**
Max. Printing width	*330320mm**
Min. Printing width	*330100mm**
Max. Printing length	10000mm
Min. Printing length	0.5mm
Thickness of printing materials	Less than 300g

Technical data

Description	Brand	Quantity	Origin
Printing roller		3sets	China
Anilox roller	Auclean/Laser	1set	China
Unwind tension controller	Mitsubishi	1set	Japan
Rewind tension controller	ZXTEC	1set	China
Main motor	Wannan	1set	china
Transducer	Mitsubishi	2sets	Japan
Magnetic power brake/clutch	Ningxia	3sets	China
Electromagnetic valve	Airtac	2 set	Taiwan
Inverter	Schneider	1set	Frence
AC Contactor	Schneider	2pcs	France
Time relay	C-LIN	1pc	China
Solid relay	Omron	6pcs	Japan
Micro relay	Weidmiiller	2pcs	Germany
Temperature Controller	Yuyao	6pcs	China
Air switches	fromSiemens	8pcs	Germany
Low-pressure wiring	Schneider	All	France
All the bearing	NSK/CHINA		JAPAN/CHINA
